OZ7000 AUGER FILLER PACKING MACHINE (SERVO CONTRELLED)

Category
:
3 OR 4 EDGE PACKAGING MACHINES (PRO)
Product Name
:
OZ7000 AUGER FILLER PACKING MACHINE (SERVO CONTRELLED)
Product Description
:
OZ7000 Sachet Packaging Machinery is a full automatic machinery with PLC control which designed for producing 3 or 4 side sealed packs. Filing System for the machine produces as Volumetric, Auger (Screw) and/or Liquid filling system according to the products to be packed Filling volume of the machine is between 10-200 ml The main usage area for this machine is to pack products like spices, sauces, soup mix, tea, coffee, cream, ketchup, mayonnaise, yeast powder, shampoo, etc

Request a Bid
Required Field:25 m2
Total Electricity Consumption:7 kW 380 V, 3 Phases 50 - 60 Hz.
Origin:TURQUE
Capacity:40 Pcs / Max
Number of Employees:1
Required / Air, Water and Fuel:6 Bar Air Presseure 300 Lt/Munite
Products
AUGER FILLER PACKING MACHINE (SERVO CONTRELLED) (OZ7000)
OZ7000 is a PLC controlled full automatic sachet packing machine, designed for producing 3 or 4 sided packages. Machine’s filling system is manufactured as volumetric, screwed and liquid dosing system; according to the products that will be packed. The machine can pack spices, sauces, instant soup, pudding, tea, sugar, coffee, coffee cream, ketchup, mayonnaise, baking powder, vanilla powder, dry yeast, shampoo etc.

GENERAL CHARACTERISTICS AND CONSTRUCTION:
The machine’s base frame has been made of stainless steel.
All the surfaces in touch with the product are made from stainless steel.
Other parts are made of aluminum.
Closing design for easy and full cleaning.
Excessive load resistant base frame system with cart stand for easy setup.
Excessive load resistant adjustable frame system for fixed position
Safety contact and the transparent protective cap is covered with plexy and it has a safety switch.
Claw device for producing a 4 sided sealed bag.
Easy to open notch device.
Suction ports for dust collecting at filling station.
Pneumatic gutter vibrator.
Stainless steel finished product exit ramp (aluminum conveyor).
Reel holder (pneumatic shaft)
Control over touchscreen (LS)
Control device is PLC programmable (LS)
Electricity equipment in accordance with CE European standardds : En 60204 Omron-Schneider-Siemens-Ls

TECHNICAL FEATURES:
Product: Powder and every shape of granulated foods.
Width: 1000 mm
Length: 2100 mm
Height: 2150 mm
Min. Package Size: 70mm/140mm
Max. Package Size: 90mm/190mm
Base frame:  Stainless steel
Weight (Approximately): 450 Kg
Electricity consumption: 7 kW
Air pressure: 6 Bar
Bobbin inner diameter: 76 mm
Bobbin diameter: Max: 300 mm
Package type: Square
Packing material: Bonds with heat PET/ALU/PE, PAPIER/PE, PET CAST,…
Impermeability cover: PLAT
Capacity: 20-70 Per/Minute
Package size adjustment with servo control between minimum and maximum values

Filling Unit:
Screwed filling (Servo Controlled). All the surfaces in touch with the product will be made from 316L quality chromium.
Screwed feeder consists of the followings
Stainless steel 316L product funnel.
Mixer.
316L Stainless steel pipe and impermeability dosing devices.
Ultrasonics level detector
Note: If it is necessary, our firm can make technical specification changes at machines without notifying beforehand.
Origin country: Made in Turkey
VOLUMETRIC WEIGHING UNIT FOR THE GRANULATED PRODUCT IN THE SAME PACKET (Optional Feature)  (H5-10)
Volumetric (Volumetric weighing)
Dosing unit for vegetables.
Stainless steel 316L product funnel.
Note: If it is necessary, our firm can make technical specification changes at machines without notifying beforehand.
Origin country: Made in Turkey
