MG 56 TS Although it is no different to others in terms of what it does, it is mainly used for small capacity applications. This is the ideal machine for concentration on one application rather than a combination of applications. Being a machine operated by a single operator, it requries minimal maintenance and works without noise and failure. Thanks to the fact that all its mechanisms, including main chasis and feet, are made of 304 quality stainless steel and metal profiles, it is long lived, even in the most difficult working conditions.
All materials and parts used during the manufacturing process of the machine have CE certification. The machine is user friendly and can support different moulds.
TECHNICAL SPECIFICATIONS:
Printed and unprinted Film: Yes
Only Bonding: Yes, in 8 minutes speed
Vacuum and Gas: Yes, 5 minute cycle
Vacuum Pump: 100 m3 / h Red Busch
Fire Movie Collection: Yes
Transaction Type: Full Auto
Air Pressure: 6 Bar
Gas Pressure: 6 Bar
Electric voltage: 380V three-phase
Machine Size: 3150 x 890 x 1520 mm
Machine Weight: 620 kg
Max. Film Width: 690 mm
Max. Movie Diameter: 340 mm
Max. Bowl Dimensions: 470x370x100 mm
Max. Bowl height: 100 mm
Min. Bowl Height: 20mm
On Easy Bowl: Optional
Mold Dimensions: Design
Note: Our company, if requires, may make changes in technical specifications of machine without prior notice.
Made in Turkey
