GENERAL INFORMATION:
• Container will be made from polyester or PVC sheets for the desired grams.
• Prepared these containers will be automatically filling in the required grams.
• Preparation of Mold making and subsequent filling of the foil top lid will close by hot gluing method.
• This filled and over glued containers will give to the output conveyor by cutting
• Manufacturer and product name will be on the cover. Package shape feature to ensure that there will be information on the cover.
• Machine surfaces that come into contact with the product will be manufactured from AISI 304 stainless steel.
• The machine will run on a minimum number of molds. Packaging will be hygienic.
• The machine is working with hydraulics and pneumatic systems and PLC controlled.
• The operator panel is touch sceen system. All information can be seen on the operator panel by pages.
• The machine frame is made from stainless steel by aluminum made in Europe.
TECHNICAL SPECIFICATIONS:
Product: Jam, Honey, Marmalade
Weight: 20gr
Elektric:220-380V 3 phase
Elektric consumption: 10kW/h
Required air: 300lt/min (6 bar)
Required water : 10lt/min
Oparator: 1 person
Capacity: 15-20 times/min
Mold: 8
Shape of the mold: Will be made according to the dimensions given
Machine weight: 2000kg (approximately)
Made in Turkey
Note: Our company, if requires, may make changes in technical specifications of machine without prior notice.
