BSM-32x100 COMBINED SYSTEM BISCUIT LINE CAPACTY 600 KG H

Category
:
BISCUIT MACHINES
Product Name
:
BSM-32x100 COMBINED SYSTEM BISCUIT LINE CAPACTY 600 KG H
Product Description
:
In the combined biscuits line, both (soft chip cookies) from rotary line pavoni biscuit dough as well as chisel biscuits (hard paste)  used in the production of biscuits dough cutting base. with a line of a minimum capacity  300 kg / h,  and with a line of maximum capacity 1000 kg / h of product can be obtained.

Request a Bid
Required Field:45m. x 10m.
Total Electricity Consumption:125 kw./h.
Origin:TURQUE
Capacity:600 kg./h.
Number of Employees:16 workers / shift
Required / Air, Water and Fuel:30 m³ / h. Natural Gas/ 6 Bar Air Presseure
Products
SYRUP TANK (500 lt. / double jacket) (BSM600)
It is a tank entirely made of stainless steel alloy for preparing invert syrup solution made by boiling the mixture of water, sugar, and citric acid in this tank.
It is heated from bottom by natural gas for boiling the ingredients. A driving group consisting of 1,1 kw motor linked with 60 cycle / minute reductor mix the ingredients during boiling. A pump located under this tank pumps the Invert Syrup to the resting tank.
Tank Capacity: 500 lt.
Mixer motor power: 1,1 kw.
In side diameter: Ø 80 cm.
Height: 100 cm.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
SYRUP RESTING TANK (500 lt.) (BSM601)
The “Syrup Resting Tank” is entirely made of stainless steel for resting the prepared invert syrup solution. By using the discharging stopcock located under the tank, the desired quantity of the syrup can be obtained.
Capacity: 500 lt.
In side diameter: Ø 80 cm
Height: 100 cm
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
OIL MELTING AND RESTING UNIT (BSM602)
It is a tank for melting and resting the blocks of vegetable oil (margarine) packed in 20 kg pack each to be able to be used in the processing. The water is heated between 60ºC - 80ºC by electrical resistance and circulated by heat exchanger. This is ensuring melting of the margarine blocks and the melted oil is collected in this double-jacketed tank.
The tank is entirely made of stainless steel. It has a cover which can be opened easily with the shock absorber. The water temperature can be regulated in any desired degree by an electronic thermometer and the circulation can be done. Its capacity for stoking oil is 500 kg. The total used resistance is 9000 of watts.
The desired quantity of oil is discharged from this tank to the mixer by the dosing pump. The power of Dosing Pump is 0.25 kw.
Width: 160 cm
Height: 145 cm
Length: 170 cm
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
DOUGH MIXER (High Speed, 600kg./h.) (BSM603)
It is a mixer with Z stirrers used for preparing and mixing biscuit dough. It has a stainless steel hopper of 250 liter capacity and double-axes Z stirrers inside made of stainless steel. 500 kg/h capacity per two charges and step-less speed adjustability between 30 cycle/min to 60 cycle/min.
The trough of this mixer has a system to discharge it by lifting and turning it down.
Motor power:  50 Kw.
Sizes:
Width: 150 cm
Lenght: 180 cm
Height: 200 cm
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
CREAM MIXER (300kg./h.)** (BSM604)
It is completely made of stainless steel, used for preparing cream. It has a planet type mixer. This type of mixer turns both around itself and around the circumference of the Mixer Tank during mixing. It is Double-cycle mixer.
Capacity: 300 kg. / h.
Power:
3 kw for 30 cycle outlet.
4 kw for 60 cycle outlet.
Width : 800 mm.
Length : 1000 mm
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
WASTE BISCUIT MILL (BSM605)
It is a mill that has a “rotating head with knives” for grinding waste biscuits to become fine and powdery as flour to be used again in the plant.
Capacity: 200 kg / h.
Motor Power: 2,2 kw.
Sizes:
Width: 70 cm
Lenght  :  100 cm
 Height  :  150 cm
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
POWDER SUGAR MILL (BSM606)
It is a mill which has a rotating head with pallets for producing powder sugar from the ordinary crystal sugar.
Capacity: 500 kg / h.
Motor Power: 2,2 kw.
Sizes:
Width:   80 cm
Lenght  :  120 cm
Height: 150 cm
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
DOUGH LIFT (BSM607)
SHEETER*** (BSM608)
It is a machine which is makes sheets from block hard biscuits dough.
It makes, between 5 mm to 30 mm thickness and 100 cm wideness sheets.
There are two channeled top cylinders and two flated down cylinders.
Top cylinders motor: 3 Kw.
Down cylinders motor: 2,5 Kw.
Band motor: 1,1 Kw.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
LAMINATOR*** (BSM609)
It is ensuring the dough to be laminated and folded 6 laminas to give the salted dough crispy feature in the cracker type products.
The unit is entirely made of stainless steel.
Its total motor power is 3 kw. It is possible to run it steplessly in speedy or slowly way.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
I.CYLINDER GROUP*** (BSM610)
This cylinder group brings the dough laminas coming from the Laminator in 20 - 30 mm thickness to a dough laminas of 1.000 mm wideness and 8 - 10 mm thickness.
The cylinders are made of Chrome - Nickel alloy.
Its total motor power is 5 kw. It is possible to run the cylinders steplessly in speedy or slowly manner.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
II. CYLINDER GROUP*** (BSM611)
This cylinder group descends the thickness of dough laminas coming from the I. Cylinder Group in 8 - 10 mm to 4 - 6 mm of thickness and spread it to 1.000 mm wideness.
The cylinders are made of Chrome - Nickel alloy.
Its total motor power is 4 kw. It is possible to run the cylinders steplessly in speedy or slowly manner.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
III. CYLINDER GROUP*** (BSM612)
This cylinder group thinners the thickness of dough laminas coming from the II. Cylinder Group in 6 - 4 mm to 2 - 3 mm of thickness and spread it to 1.000 mm wideness.
The cylinders are made of Chrome - Nickel alloy.
Its total motor power is 3 kw. It is possible to run the cylinders steplessly in speedy or slowly manner.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
RESTING CONVEYOR***  (BSM613)
It is a belt used for taking off the tensions (strains) being inside the dough. Its motor power is 0.75 kw.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
ROTARY MOULDING MACHINE** (BSM614)
It is a machine which makes biscuit form into dough at soft dough
biscuit production.
It is pressing   to pressed  dough into rotary moulder.
And soft dough biscuit comes from moulder to the oven.
Moulder width: 1000 mm
Pressing cylinder power. : 2.2 kw.
Band motor Power: 1,1 kw.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
CUTTING MACHINE*** (BSM615)
It is a machine working with special designed mould. When hard dough is in use, it cuts the dough according the desired biscuit pattern.  The hard dough preparation is in 1.000 mm wideness and in 2 - 3 mm thickness when it enters in this machine. Its motor power is 1.1 kw. It is possible to run the mould and the belt step-lessly in speedy or slowly manner.
Moulds Motor: 0.75 Kw.
Band Motor: 0.75 Kw.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
SCRAP SEPERATING MACHINE*** (BSM616)
It is a machine for separating the fragments and crumbs left back after the cutting mold pressed the dough and gave the biscuit motif to the dough. These fragments and crumbs are outside the biscuit border and this machine separates them by lifting them up.
Total motor power needed is 0.37 kw. Its speed can regulated step-lessly in speedy or slowly manner. The belt used here is PVC base cotton fabrics.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
SCRAP RETURNING CONVEYOR*** (BSM617)
This belt returns the crumbs back to the sheeter to be mixed again with the new dough. It is entirely made of stainless steel. Its running belt is made of PVC base cotton fabrics.
It has a motor of 0.75 kw. The belt speed can regulated step-lessly in speedy or slowly manner.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
OVEN INLET CONVEYOR  (BSM618)
It is a PVC base fabric belt ensuring the transition of the “biscuit shaped dough” to Oven Belt. Its motor power is 0.75 kw. The belt speed can regulated step-lessly in speedy or slowly manner.
Band width: 110 cm
Motor power:  0.75 Kw.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
OVEN (32 MT) (1MT) (BSM619)
This oven is indirect heat type oven. The air heated in Combustion Chamber by a burner using LPG or natural gas is circulate in special channels of the Tunnel Oven by a fan.
Due to the special design of the oven, the product is never coming in touch with burned gases during baking. The product is being baked during running forward in the Baking Tunnel without touching the burned gases. The heating for baking the product is indirect heat.
The elements used in the structure of the Tunnel are made of high heat resistance Chrome - Nickel Steels & Carbon Steel.
The baking rooms of the oven are isolated entirely by a nun-conductive isolation material.
The wire-mesh belt existing inside the oven is ensuring hot air circulation from the bottom during running to give a homogeneous heat to all faces of the product. This is an automatic regulation and security system to prevent the belt from slipping left or right.
This belt speed can be regulated between 2 m / min - 7 m / min.
The total length of the oven is 32 meters consisted of 2 units of which each one of them produces 150.000 kcal / h of heat. The belt wideness in the units is 100 cm and length is 16 meter in each unit.
The heat of the oven can be regulated automatically between 100°C - 300°C.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
180° TURNING BELT  (BSM620)
It can turn and carry the products 180O without undo lines.  It has adjustable speed poliuretan belt.  belt wideness is 1000 mm, and turning axle 2.500 mm.
Electric power: 0,75 Kw.
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
COOLING AND COLLECTING CONVEYOR (84 MT)  (BSM621)
BISCUIT SANDWICHING MACHINE (1.600 pcs./m.) (BSM622)
It strews between two biscuits and it makes sandwiched.
Capacity for double head machine is 800 p. / m. Sandwiched biscuits.
Cream pumping automatically from cream storage.
There is a band for biscuit stocking in front of the machine.
Total power:  4,5 Kw.
Sizes:
Width:  150 cm
 Lenght:   50 cm
 Height: 150 cm
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice..
Made in Turkey
