This machine has PLC Computer programming and HMI operation interface, speed adjustment with variable frequency and electronic brake features. Since the machine has entered into the market, it has a very good prestige and reputation because of its excellent practices by combining all devices in a single machine. It is an ideal choice for you in production of high quality toilet rolls and kitchen towels and also, it can increase the economic advantages by reducing the consumption.
1. Diameter of Finished Goods: ф90-200 mm, Inner-Bobbin diameter: ф25-50mm
2. Dimensions of Paper to be Attached: Max. Width: 1750mm, max. diameter (external): ф1100mm
3. Weight of Paper to be Used in Gram: 13-28g/m2 (single layer)
4. Capacity: Max: 200m/Minute, (Sheet length 115mm,220 sheets, 1 log finishes in 12 seconds)
5. Perforation: 4 spiral blades are mounted onto a perforated roll, perforation length is 115mm±1mm (Perforation adjustment will be made through Inverter)
6. Features:
a) Coil Stand: 2 paper loading stands will be available, pneumatic paper loading, paper will be transferred through pneumatic wide speed adjusted belt.
b) Machine will be equipped with warning system (light) & automatic stop system against paper breakages and bobbin finishing.
c) PLC control, speed control frequency-converter and HMI operation interface, touch screen.
d) Automatic sheet number calculation and hardness control of finished product are checked through air pressure and electron.
e) Micro computer (computer) product hardness control.
f) Automatic bobbin loading, pasting, edge pasting, cutting are made synchronously.
g) Embossing & (1 sets Laminating) : Total 3 sets of embossing will be available. 1 set of Steel-Rubber (Pneumatic) (For Toilet Paper) , 2 sets of steel-rubber for disinfection and laminated roll towel (Pneumatic).
h) Electric power: 380V,50Hz,3P (Others should be reported.) Control voltage: DC24V.
Machine Dimensions: L: 9500mm W: 2100mm H: 2100mm
Machine Weight: 7000kg
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice.
Made in China
