Rotor blades: 110x25x500 10 pcs ( 2 pcs x 5 rows )
Number of fixed blades: 110x25x500 4 pcs ( 2 pcs x 2 rows )
Rotor length: 1000 mm
Rotor blade length: 500 mm
Rotor diameter: ~ Ø650
Rotor shaft speed: 650 rpm, Can be adjusted depends on material.
Blade material: DIN 2379 ( AISI D2 )
Motor power: 90 kW 1500rpm
Screen Hole Diameter: 12-14 mm (Hole diameter of spare screen will be decided according to customer’s request)
Cooling system : Water-cooled ball bearings
Safety switches: 1 pcs
Output Capacity: 500 - 600 kg/h
Made of heavy-duty steel and sheets, completely by gas welding manufacture.
Horizontal profiles in the funnel prevent the material from deflecting back during the first breakage.
Heavy-duty type bearings easily absorb the crushing impacts.
Distance between Fixed and circular blades and screen can be adjusted very easily in such a short time.
Power is transferred to the rotor via the B-type V belts in the safety shelter.
Crushing Machine is designed to allow automatic opening closing of the body via the hydraulic unit in order to prevent wasting time for replacing the blades.
In order to extend the lifetime of the blades and increase the product of the crushing process, the rotor and fixed blades are made of DIN 2379 material and heat-treated at 58 HRC temper.
1 set of spare blades and 1 screen is included as spare part.
Our machines have TSE, Warranty Certificate, After Sales Compliance Certificate and CE certificates.
