AUTOMATIC WIRE NAIL MAKING PLANT WITH ACCESSORIES 35 MM -80 MM

Category
:
AUTOMATIC WIRE NAIL MAKING PLANT WITH ACCESSORIES (PRO)
Product Name
:
AUTOMATIC WIRE NAIL MAKING PLANT WITH ACCESSORIES 35 MM -80 MM
Product Description
:
AR Series machines are advanced technology serial production machines developed for production of nail etc. from steel, copper, brass and aluminum alloys in compatible with use of round or square section wire. With easily changeable, simple and plain cutting fitting, all kinds of tip forms can be applied easily. Although its production area is highly large, compatibility of diameter and length values with related nail standards is guaranteed subject to used wire resistance and production capacity. Rational design of the machine offers many advantages together

Request a Bid
Required Field:30 m2
Total Electricity Consumption:15 KW / 380 V/ 3 FAZ
Origin:TURQUE
Capacity:330 - 450 Nails /Minute
Number of Employees:1 PERSON
Required / Air, Water and Fuel:-
Products
AUTOMATIC WIRE NAIL MAKING MACHINE 35MM-80MM (AR3)
The body of all our machines are specially designed cast iron gg 25 pik, and may be done cast steel upon request.  By making the bearing of the bed places of the machine reddish yellow this provide a more comfortable and trouble-free operation of the machine. By making surface hardening of all systems running of the machine the  erosion is prevented.  Form of lubrication, Central automatic lubrication system.
5,5 KW motor power
Standard Power Installation 380 3 phase 50 hz
From 35 mm. to 80 mm. Production
Machine Weight without accessories : 1967 kg
Machine Weight with accessories : 2000 kg
Lubrication system Tank capacity : 20 kg
Maxiumum Head diameter (mm)* : 8
Maximum steel wire diameter (mm) Ø : 1,80 - 2,70
Al-alloy maximum diameter wire (mm) Ø : 1,80 - 3,40
Wire minimum diameter (mm) Ø : 1,80 - 3,40
Basic Dimensions : 1800 mm * 2400 mm * 1700 mm
HTS:8463.30.00.00.00
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice.
Origin: Turkey
NAIL POLISHER SINGLE DRUM COMPLETE  (LVR1)
This machine removes the burrs that form on the nails and polishing done.
Capcty 5000 kg
Power 7.5 hp
All machine is steel
Basic Dimensions : 1350 mm * 2150 mm * 1350 mm
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice.
Origin: Turkey
ADDITIONAL SPARE CUTTER, HOLDER, AND PANSON (1 SET) (SP-AR3)
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice.
Origin: Turkey
