KEBA controller
10" Color LCD screen
Multi languages control panel (6 different languages Turkish, English, German, Russian, Spanish, Arabic)
BOSCH - REXROTH directions valves
NOVOTECHNIK ruler
YUKEN PQS proportional valve
VICKERS pump
INTERMOT hydro motor
3 Core Valves, k air valves
1 Core valve function with electrical
Screw with mixer
Robot interface according as Euromap 12 and 67 for robots
Remote control
T-Slots platens according as Euromap standard
Back pressure valve
Suck back function
Auto purge system
7-stage set of injection speed, pressure and position.
High speed function
3-stage set of pressure keeping speed, pressure, position
Automatic mold adjustment function
Unlimited mold data capacity (with USB, ethernet interface)
High precision mold protection function
3-Stage ejector system
Linear displacement transducer controls clamping position
Automatic central lubrication system
Central lubrication level and pressure sensor
Hydraulic oil tigh temperature alarm
Hydraulic oil level alarm
Micro filter system oil cleaner (RRR)
Suction filter according as euro standard
BY pass oil filter
Ceramic heater band
S.S.R temperature control
Photo sensor
Cooling water regulations with flow control and temp, indicator
Phase sequences and phase protection relay
Door safety relay
EMI - Electro magnetic interference filter
Provided mechanics, hydromechanics, electric safety system
Turkish-English warning labels
USB data connecting
Hopper dryer and auto-loader units
Movements stage and custom options can be configured from operator panel
INJECTION UNIT UNIT A B C
Screw Diameter: mm 95 105 115
ScrewL/D Ration: L/D 24,3 22 20,1
Shot Volume: cm3 3542 4321 5190
Shot Weight (PS): g 3223 3937 4723
Injection Rate: g / s 623 762 914
Plasticizing Capacity: g / s 78,8 96,33 108
Injection Pressure: Mpa 213 175 146
Maximum Screw Speed: rpm 0-120 0-120 0-120
CLAMPING UNIT UNIT A B C
Clamping Force: kN 8500 8500 8500
Opening Stroke: mm 1020 1020 1020
Space Between Tie Bars: mm 1000 x980 1000 x980 1000 x980
Maximum Mold Height: mm 1000 1000 1000
Minimum Mold Height: mm 350 350 350
Ejector Stroke: mm 300 300 300
Ejector Force: kN 200 200 200
Number Of Ejector: unit 21 21 21
GENERAL UNIT A B C
Maximum Operating Pressure: Mpa 16 16 16
Pump Motor: kW 37+45 37+45 37+45
Heating Capacity: kW 50,96 50,96 50,96
Oil Tank Capacity: L 2000 2000 2000
Machine: 11,9 x 2.75 x 2.65
Dimension (LxWxH):m
Machine Weight: t 55 55 55
