TECHNICAL SPECIFICATIONS:
Length of Screw and barrel : 25 / d {mixer system}
Diameter of screw and barrel : 80 mm.
Screw and barrel made up of : 4140 Tempered Steel
Main motor power: 18 kW. (AC Controller System/ABB Brand)
Hydraulic motor power : 7.5 kW. 1000 rpm
Head-Die Type: :Double
Die Style: Spiral Splitter
Oil tank capacity : 180 liters
Number of heater zones : 8 +1
Capacity: 25cc-2 lt.
Product Capacity: 700-760 pcs/hr for 1 lt. (Shape, thickness and weight of the final product might drop the production capacity of the machine.)
Temperature control performed by 4 zone temp control and cooler fans on barrel
All electricity equipments used : Telemechanique brand
Knife (Cutting system) : Heated Knife (ustulation) Process
Pneumatic valves used : Italian origin / Camozzi brand (24DC)
Hydraulic valves used: German origin / Wolfmann brand (24DC)
P.L.C. Control system: Japan Origin / Fuji and Fatek
Driver System: Switzerland Origin / ABB Brand
All motors: Turkish Origin / GAMAK Motors
Linear Rulers : German Origin / Novotechnic Brand
Parison Valve : Italian Origin / Atos Brand
Clamp Movements control by Servo Valves: Italian Origin / Atos Brand
Clamp Motions and Blowpin Motions controls with linear position sensors.
Clamp plate size : 400x400 mm.
Closing distance : 120 mm (minimum)
Openning distance : 570 mm. (maxsimum)
Weight of the Machine: 6700kgs
W x L x H: 225 cm. x 375 cm. x 300 cm.
Silent riggind supplied at 900 rpm motor circulation by pllet pump Soft and silent clamp motions by proportional control system Barrel - die up and down motions for each parison cutting process Platform Adjustment upto 300mm for different moulds
Hydraulic Blowpin system
Hydraulic Deflashing Unit
Automatic raw material loader
Parison control System (Adjustment of the thickness of the surface of the product from 200 points up to multi- points.)
Note: Our company reserves the right to make changes in technical specifications of the machines as deemed necessary without prior notice.
Made in Turkey
